Installation and Use
INSTALLATION
Mechanical installation:
You most likely need to move your mirror-clutch assembly just few millimeters to get the needed space (9 mm) for SilverFox clamp arm.​​
​
Slide the plastic adjustment ring on to the 22 mm handlebar. By rotating the adjustment ring you can move the controller forward or backward on the motorcycle handle bar. Clamp the device on the adjustment ring evenly with two M4 screws.
​Connect the power cord to the fuse protected 12VDC output (post ignition) of your bike (Operating voltage range 5-24VDC). Double check to make sure to connect the cords are correct; Brown wire to negative (-) and White wire to positive (+).
​​​​​
H1 (from 5/2024) and C1 units are supplied with M12 connectors to plug&play with DMD T865 harness. And with extra cable strip for just 12VDC power feed for other systems. ​
​Connect bluetooth:
Power on the SilverFox navigation controller. Open the Bluetooth settings on your Android device. Find and tap on the device e.g. "SilverFoxH1" from the list of devices. Accept the pairing request. Your SilverFox navigation controller is now paired using Bluetooth.
​
Install the Button app:
Download Button app , unzip it and install it to your Android device. On first run the app will ask to enable the the accessibility service for Button app. Follow the link and allow the service and permission to use the app. Please check the video. Demo done with Samsung Activetab 3, Android 13 OS.
​
​
​​​​
If you bought your B8J device from Thork Racing (1/2023 - 2/2024), the Firmware is already compatible with Button app.
​​​​F1-keyset:
Choose for map applications such as DMD2, OsmAnd, LocusMaps, Google Maps, Waze, Gaia GPS, etc. (listed in Button app).
​
Panning Joystick movements correspond with left, right, up and down map movement.
​​
Control Joystick forward and back movements corresponds to zoom actions
​
Control Joystick up centers the map to your current position. Holding the button changes the map orientation to the north (if the selected nav application supports the function)
​
F2-keyset:
Choose for apps that has special key mappings like Mapitare, Ranniot, Tracker. You can also use this with Locus Maps or Osmand built in customizible controller commands.
​
Panning Joystick movements correspond to left, right, up, and down map movement.
​
Control Joystick up => letter 'C' for centering the map​
Control Joystick up and hold => letter 'D' extra functions on some apps
​
Control Joystick forward => character '-' and KEY_NUM_MINUS
Control Joystick forward hold + => letter 'A'
​
Control Joystick backward => character '=' and KEY_NUM_PLUS​
Control Joystick backward and hold - => letter 'B'
Center
Zoom
F1/F2
(hold)
Zoom
Control Joystick
Panning Joystick
​Operating the C1 units
​
The Keysets:
​
The C1 controller has two selectable keysets. Both keysets are pre-programmed to send different key codes to the Android device. For example, the "zoom in" button sends a different command in the F1 mode than in the F2 mode. The C1 controller remembers the keyset state from when it was last powered off.
​
To change the keyset on the C1 controller, press and hold the "Control Joystick" down. The LED corresponds to active F-state
​
You can change the Zoom direction by briefly pressing down on both joysticks simultaneously.
​
​​
Center
Zoom out
Zoom in
Panning Joystick
​Operating the HomeOne and B8J units:
​
The Keysets:
​
The controllers has two selectable keysets. Both keysets are pre-programmed to send different key codes to the Android device. For example zoom in -button send different command in F1 set than in F2 mode. HomeOne device remember the keyset state when you power off the unit. B8J starts in F1 keyset.
​
Changing the keyset in B8J has a F1/F2 button on top of the unit. When LED is on, the F1 is activated. LED off and you are in F2 mode.
​​
In HomeOne and HomeOne+ controller press both Zoom buttons at the same time, toggles between F1 and F2 ​
​
F1-keyset:
Choose for map applications such as DMD2, OsmAnd, LocusMaps, Google Maps, Waze, Gaia GPS, etc. (listed in Button app). SilverFox B8J starts in F1 mode.
​
Joystick movements corresponding left, right, up and down
​
+ and - buttons are zoom in and out
​
centering/orientation button center the map to your current position. Holding the button changes the map orientation to the north (if the selected nav application supports the function)
​
F2-keyset:
Choose for apps that has special key mappings like Mapitare, Ranniot, Tracker. You can also use this with Locus Maps or Osmand built in customizible controller commands.
​
Joystick movements corresponding left, right, up, and down
​
Center => letter 'C'
​
Center hold => letter 'D'
​
+ => character '=' and KEY_NUM_PLUS
​
Hold + => letter 'A'
​
- => character '-' and KEY_NUM_MINUS
​
Hold - => letter 'B'
